BINDER premium 25 AT20 GEN III

BINDER premium 25 AT20 GEN III

BINDER access 150 AT20 SYN

BINDER premium 32 AT20 GEN III

Synchroflex® standard belt

Download the 3D file

Download PDF

Grayed out functions require you to be logged in to your account

login to my account

Tangential force transmissible by the teeth Product range Technical characteristics Mechanical data Masses and dimensions Kinematic data

Tangential force transmissible by the teeth

Range: BINDERpremium

Product range power belts: Synchroflex® standard belt

Applications: Precision application

Profile / Pitch: AT20

Profile: AT

Pitch: 20

PU Material steel tension member: DNHU 9333

Shore hardness steel tension member belt: 93 ShA

Temperature range of steel tension member belt: -20 à 100 °C

Winding: wire

P max: ≤250 kW

Steel tension member permissible force FN: 6300 N

N max: 6500 tr/min

V max: 40 m/s

Standard belt lengths: 1000, 1200, 1600, 1760, 1260, 1960, 1500, 1800, 1100, 1700, 1900 mm

Belt width: 25 mm

Weight: 0,29 kg/m

Number of teeth: 80, 90, 85, 55, 60, 75, 95, 98, 50, 88, 63

Z min single bending standard cable: 18

Ø min Flexion simple câble standard: 120 mm

Z min alternating bending standard cable: 25

Ø min alternée simple câble standard: 180 mm
