BINDER access 25 AT20 SYN

Synchroflex® standard belt

Power belts
Grayed out functions require you to be logged in to your account
login to my account
Tangential force transmissible by the teeth
Range
BINDERaccess
Product range power belts
Synchroflex® standard belt
Applications
Precision application
Profile / Pitch
AT20
Profile
AT
Pitch
20
PU Material steel tension member
DEDU 8600
Shore hardness steel tension member belt
88 ShA
Temperature range of steel tension member belt
-20 à 80 °C
Winding
wire
P max
≤200 kW
Steel tension member permissible force FN
5200 N
N max
6500 tr/min
V max
40 m/s
Standard belt lengths
1000, 1200, 1600, 1760, 1260, 1960, 1500, 1800, 1100, 1700, 1900 mm
Belt width
25 mm
Weight
0,264 kg/m
Number of teeth
80, 90, 85, 55, 60, 75, 95, 98, 50, 88, 63
Z min alternating bending E cable
22
Z min single bending standard cable
18
Ø min Flexion simple câble standard
120 mm
Z min alternating bending standard cable
25
Ø min alternée simple câble standard
180 mm
Z min single bending E cable
15
Ø min Flexion simple câble E
100 mm
Ø min alternée simple câble E
150 mm
Z min single bending stainless steel cable
32
Ø min Flexion simple câble Inox
200 mm
Z min alternating bending stainless steel cable
40
Ø min alternée simple câble Inox
300 mm
