BINDERclassic 32TK10K13 basic M

BINDERclassic 32TK10K13 basic M

BINDER ACCESS 100 T10 CLA M

BINDERclassic 50TK10K13 basic M

BRECObasic® belt

Download PDF

Grayed out functions require you to be logged in to your account

login to my account

Tangential force transmissible by the teeth Product range Technical characteristics Mechanical data Masses and dimensions

Tangential force transmissible by the teeth

Range: BINDERaccess

Linear belt product range: BRECObasic® belt

Application: Self-guided precision application

Profile / Pitch: TK10

Profile: TK

Double toothed belt: no

PU Material steel tension member: Grey TPU BAS

Shore hardness steel tension member PU belt: 92 ShA

Temperature range of steel tension member belt: 0 to 80 °C

Winding: S+Z

Weight: 0,282 kg/m

Guide profile: K13F

Constant stiffness of the CSPE reinforcement (steel): 0,70*10^6 N

Steel tension member permissible force FN: 2600 N

N max: 10000 tr/min

V max: 60 m/s

Width tolerance: +/- 0.5 mm

Pitch: 10 mm

Belt width: 32 mm

Length tolerance: +/-0.8 mm

Thickness tolerance of the tooth: 0,1/-0,3 mm

Tolerance of thickness of the tooth: 0/-0.1 mm

Z min alternating bending stainless steel cord: 40

Ø min alternée simple câble Inox: 130 mm

Z min single bending standard cable: 25

Ø min Flexion simple câble standard: 80 mm

Z min alternating bending standard cord: 25

Ø min alternée simple câble standard: 80 mm
