BINDER PREMIUM 32 AT10 DC JM

BINDER PREMIUM 32 AT10 DC JM

BINDER CUSTOM 100 T10 CLA PIN

BINDER PREMIUM 50 AT10 DC JM

BRECO® QuickLock mechanical junction standard belt BRECO®

Download PDF

Grayed out functions require you to be logged in to your account

login to my account

Product range Technical characteristics Mechanical data Masses and dimensions Kinematic data

Range: BINDERpremium

Product range: BRECO® QuickLock mechanical junction standard belt BRECO®

Application: Low charge application

Profile: AT

Pitch: 10 mm

Double toothed belt: no

PU Material steel tension member: White TPU ST1

Shore hardness steel tension member PU belt: 92 ShA

Temperature range of steel tension member belt: 0 to 80 °C

Winding: S + Z

Tension member steel permissible stress mechanical fastener: 550 N

Width tolerance: +/- 0.5 mm

Belt width: 32 mm

Length tolerance: +/-0.8 mm

Total thickness tolerance: -0.1/+0.3 mm

Thickness tolerance of the tooth: 0/-0,1 mm

Z min single bending steel cord: 25

Ø min Flexion simple câble acier: 80 mm

Z min alternating bending steel cord: 25

Ø min alternée simple câble acier: 120 mm
